    Dark Blue 2 layer PCB Fabricating

    Model :  Dark Blue  2 layer PCB Fabricating

    Material :  FR4

    Layer :  2Layers

    Color : Dark blue/White

    Finished Thickness :  1.2mm

    Copper Thickness :  1OZ

    Surface Treatment :  Immersion Gold

    Min Trace :  4mil(0.1mm)

    Min Space :  4mil(0.1mm)

    Application : Digital pcb


    Product details Technical specification

    Company introduction

    iPcb.com company specialized with the RF PCB manufacturing for more than 17 years in China. We know how much the proper RF material would affect to the performance of the board .The parameters such as RF microwave energy levels ,operating frequency, operating temperature range ,current and voltage are of great importance when choosing the suitable material for the high frequency PCB fabricating. Getting familiar with those RF PCB material is one of our job ,Check below material listing for refer. We have enough of them in stock to ensure the fast delivery.The confidence towards our product quality is from our experiences engineers / production team, They cooperate closely with our QA department to provide a qualified product, We didn’t expect to achieve a big thumb from our customers, But more and more repeat orders speak out the satisfaction of them. Quality is the core value of our company, We know the importance of quality for a long-term business, Thanks very much to our customers that accompany with us to developed / improved our capacity and technical field for the past 17 years.



    Surface finishing: OSP / ENIG / HASL LF / Plated gold / flash gold / Immersion Tin / Immersion silver / Electrolytic gold


    Capacity: Golden finger / Heavy copper / Blind buried via / impendance control / filled with resion / carbon ink / backdrill / countersink / depth drilling / half plated hole / pressfit hole / peelable blue    mask / peelable solderstop / thick copper / oversize


    Material: Rogers RO4350B / RO3003 / RO4003 / RO3006 / RT/Duroid 5880 / RT5870 and Arlon / Isola / Taconic / PTFE F4BM / Teflon material etc.


    Layer: 2L 4L 6L 8L 10L 12L 14L 16L 18L 20L 22L 24L 26L 28L 30L


    Dielectric Constant (DK):  2.20 / 2.55 / 3.00 / 3.38 / 3.48 / 3.50 / 3.6 / 6.15 / 10.2


    Application: Consumer Electronics / Military/Space / Antenna & Communications System / High Power / Medical / Automotive / Industrial / Handheld device cellular / Wifi Antenna / Telematics and infotainment / Wifi/Computing/Radar/Power Amplifiers




    For pcb technical problems, ipcb knowledgeable support team is here to help you with every step. You can also request pcb quotation here. Please contact E-mail sales@ipcb.com

    We will respond very quickly.

    Model :  Dark Blue  2 layer PCB Fabricating

    Material :  FR4

    Layer :  2Layers

    Color : Dark blue/White

    Finished Thickness :  1.2mm

    Copper Thickness :  1OZ

    Surface Treatment :  Immersion Gold

    Min Trace :  4mil(0.1mm)

    Min Space :  4mil(0.1mm)

    Application : Digital pcb



    For pcb technical problems, ipcb knowledgeable support team is here to help you with every step. You can also request pcb quotation here. Please contact E-mail sales@ipcb.com

    We will respond very quickly.
